Knob Control Panel

Knob Control Panel

  • This Smart Knob Control Panel adopts the RTOS platform, integrates a 3-way relay, mainly provides switch in situ replacement, intelligent device control, and scene panel functions, standard 86 base, installed in the user's home 86-box, the user can manage and control the home device in the interactive way of knob, screens, buttons, and so on.
View full details

Datasheet

Features

  • Ultra-smooth Knob & Touchscreen: Precise control at your fingertips, delivering butter-tery-smooth rotation as fluid as water.
  • 3-channel Relay & 4 Customizable Switches: Efficient control combining three relay circuits with four programmable physical buttons.
  • Built-in Pomodoro Timer: Countdown alerts for optimized time management in daily tasks.
  • Device & Scene Integration: Centralized smart device control for streamlined management.
  • Next-gen IoT Chipset: Powered by a high-performance RTOS (Real-Time Operating System), ensuring rapid and stable response.

Parameters

  • 1.6'' Knob TUYA Central Control Panel (RTOS System)
  • UItra-Smooth Konb & Touch Screen
  • 3-Channels Relay & Customizable Switches
  • Built-in Pomodoro Timer
  • Device & Max 10 Scenes Integration
  • Input: 100-240VAC, 50/60Hz
  • 3 Relays, Max Load: Single 200W, Total 600W
  • Load types: FL, CFL, LED lamps
  • Microphone*2, Loudspeaker*1, 1W
  • Resolution 400*400, TFT Display, 1.6''
  • Built-in Conformal Antenna
  • Work Temperature: 0~40°C
  • Work Humidity: 5~90%RH Non-Condensing
