Features
- Biometric Recognition: Dual-sided fingerprint scanning (100 profiles), facial recognition (50 profiles), and palm vein authentication (50 profiles) with 0.5-second response time, resistant to fake fingerprints/photos.
- Multiple Access Methods: Password, IC card, NFC, remote control (1,000 profiles total) + Tuya Smart App remote unlocking.
- Emergency Backup: Hidden mechanical keys (dual-key design) + USB-C emergency power supply.
- 1080P Wide-Angle Camera: Infrared night vision for 24/7 monitoring; automatic capture and alerts for suspicious activity.
- Two-Way Audio: Communicate with visitors remotely via the Tuya App, and grant temporary access codes for deliveries or guests.
- Robust Construction: CNC-machined aluminum front panel, high-strength alloy rear casing/auxiliary lock, and 304 stainless steel dual-hook latch for anti-sawing and anti-prying.
- Dual-Layer Panel Protection: Brushed acrylic + 9H tempered glass surface, scratch-resistant and impact-tested over 10,000 cycles.
- Active Defense: Anti-prying alarm, false password siren deterrent, and low-battery alerts (synced with app notifications).
- Convenience: Auto-locking upon closure and built-in doorbell.
Parameters
- Unlocking Methods: Fingerprint (inside/outside), Password, NFC Card, Face Recognition, Remote Control, Palm Vein, Mechanical Key (inside), Tuya App Remote Unlocking (active)
- User Capacity: Face: 50; Palm Vein: 50; Fingerprint: 100; Passwords/NFC/remote keys: 1000
- Power Consumption: Working Current: <200mA
- Operating Temperature: -20°C to 80°C (-4°F to 176°F)
- Battery: Capacity: 4200mAh (Optional 5000mAh)
- Dimensions: 296mm × 141mm × 97mm (11.65in × 5.55in × 3.82in)
- Weight: 1.7kg
- Material:
- Front Cover: CNC-machined aluminum alloy
- Rear Cover/Secondary Lock Body: Aluminum alloy
- Lock Latch: 304 stainless steel dual-hook design
- Panel: Brushed acrylic + tempered glass
- Anti-Tamper Alarms: Anti-pry alert, fake password alarm (triggers siren), low-battery reminder, auto-locking.
- Smart Connectivity:
- Remote video intercom via peephole (Tuya App)
- Live monitoring, temporary passcodes, and user permission management.
- Emergency Power: Type-C port for external charging during power loss.
- Door Types: Iron gates, security doors, sliding doors.
- Smart Ecosystem: Integrates with Tuya Smart Home for remote control and automation.
