Glass Door Lock

Glass Door Lock

Protocol
  • With a simple and elegant design, the whole lock body is made of zinc alloy material. The double hook bolt design and semiconductor fingerprint head make the lock safer. The dual motor protection mode of the clutch + program makes the motor non-stuck.
  • Stylish appearance: The wide full-screen design, and seamless touchscreen display with personality, and simplicity.
  • Metal material: The front and back panels of the lock are made of zinc alloy, and the integrated panel is more durable
  • Fingerprint recognition: The dual-sided fingerprint sensor design allows for more convenient door opening. The semiconductor fingerprint head recognition is not only sensitive and fast, but also effectively prevents fingerprint copying. It features enhanced identification capabilities for various conditions including wet/dry hands, elderly users, and children's fingerprints, while maintaining high security standards.
  • Dual protection motor: With a program + clutch design, the dual-protection motor is with automatic control device, which effectively prevents the motor from damage. It makes the motor precise and powerful and works without stocking.
  • Unlocking mode: 6 unlocking designs - Fingerprint unlocking, password unlocking, magnetic card [ID card, bank card] unlocking, remote unlocking, Bluetooth unlocking, small program unlocking, and wireless attendance.
View full details

Datasheet

Features

  • Stylish and simple: the lines and arcs formed in one body are truly beautiful with personalized style and sense of The Times
  • Metal material: Aluminum alloy casting, multi-layer treatment process, wear-resistant, high temperature, corrosion resistant and durable
  • Dual fingerprint card: outside fingerprint password card, inside fingerprint card key
  • Attack protection: If you enter the wrong key for five consecutive times, the system automatically locks up for three minutes\
  • Intelligent anti-snooping: intelligent protection, virtual 3-14 bit touch anti-snooping password design

Parameters

  • Unlock standard: fingerprint, password, magnetic card (NFC), Bluetooth applet.
  • Optional: Remote control, remote unlock
    Supported Platform Graffiti Intelligence (TUYA)
  • Product functions Sino-English switching, human voice operation, doorbell, automatic locking, anti-prying alarm, low power alarm, emergency power supply, time normally open mode
  • Applicable door partition door
  • Body color matte black
  • Capacity fingerprint (semiconductor identification): 100
  • Password + card + Remote control: 1000
  • Unlocking record: 30000
  • Resolution 120*120
  • The rejection rate was <3%
  • The recognition rate was 0.001%
  • Card Type M1
  • Static current <80UA
  • Working current <200mA
  • Operating temperature -30℃~80℃
  • Relative humidity RH0~92%
  • Power Supply Type 1.5V 4 alkaline batteries No.5
  • Power supply life approx. 10 months
    (average unlocking 10 times)
  • Scanning time <1S
